API 11B oil Solid Sucker Rod oilfield pump oil production pump

SIZE
(in)

ROD D.(in)

THREAD D.
(in)

LENGTH
(ft)

OUTSIDE DIAMETER
OF PIN SHOULDER(mm)

LENGTH
OF PIN(mm)

LENGTH OF WRENCH
SQUARE(mm)

WIDTH OF WRENCH SQUARE(mm)

5/8"

5/8"

15/16

2
4
6
8
10
25
30

31.75

31.75

≥31.75

22.23

3/4"

3/4"

1-1/16

38.10

36.51

25.40

7/8"

7/8"

1-3/16

41.28

41.28

1"

1"

1-3/8

50.80

47.63

≥38.10

33.34

1-1/8"

1-1/8"

1-9/16

57.15

53.98

≥41.28

38.10

No.

Grade

Tensile Strength
Rel(Mpa)

Yield Strength
Rm(Mpa)

Percentage Elongation A(%)

Contraction Percentage Of Area Z(%)

1

C

620-795

≥415

≥13

≥50

2

K

620-795

≥415

≥13

≥60

3

D

795-965

≥590

≥10

≥50

4

KD

795-965

≥590

≥10

≥50

5

HL

965-1195

≥795

≥10

≥45

6

HY

965-1195

——

——

——

Dimention

Length(ft)

Pieces/bundle

Net Weight

(KG)

Gross Weight

(KG)

Remarks(L×W×H)

mm

Adapted Container

Pieces of every Container

5/8"

25

150

1930

1938

7930×550×330
8300×550×330
9440×550×330

40'GP/40'OT

1920

26

150

1945

1953

1920

30

150

2210

2218

1690

3/4"

25

100

1850

1858

1345

26

100

1865

1873

1334

30

100

2120

2128

1174

7/8"

25

80

1920

1925

1039

26

80

2012

2017

991

30

80

2290

2290

897

1"

25

60

1915

1923

780

26

60

2006

2014

744

30

60

2278

2283

657

1-1/8"

25

50

2044

2052

609

26

50

2135

2143

583

30

50

2392

2398

521
